21cfm V Type Twin Cylinder 3hp Double Stage Air Compressor

3.53CFM V Type Twin Cylinder 3HP Double Stage Air Compressor Pump Head 175PSI

Welcome to Khshiney 🌹

Pneumatic Air Compressor Pump Motor 3HP Aluminum 175PSI  2 Cylinder 2200w SALE



Description:

The pump head of this air compressor is made of aluminum cylinder head, which can supply air faster, dissipate heat quickly, not easy to damage, compact structure and lower noise. It has the characteristics of high efficiency, high precision, low energy consumption and strong versatility.



Specifications:

Model: V-0.25/12.5

Power: 2.2KW

Main wheel: 250 mm

Pipe interface American: 3 / 4-16(19mm)

Cylinder diameter: 65 * 1 + 51*1 mm

Compression level: secondary compression

Maximum pressure: 175psi  3HP

Installation hole distance: 170 * 90mm

Material: Cast Iron

Product size: 35*25*32cm

Package size: 38 * 37 * 29 cm

Net weight: 13.7kg

Driving mode: Pneumatic



Features:

Suction and exhaust valve design: the hair piece is made of  special valve steel with excellent strength and toughness at high temperature.

Host belt design: strict balance support correction, to ensure the host running balance, strong cooling blade, better heat dissipation.

It has the characteristics of high efficiency, high precision, low energy consumption and strong versatility.



Attention:

First, it should match the motor power

Second, the head and motor pulley must be kept in a straight line to avoid bearing displacement

Third, before using a new machine, you must add oil first. Change the oil for half a month for the first time, one and a half months for the second time, and change the oil for the next four to five months. Pay attention to observation at ordinary times. If it is not enough, replenish it in time. Keep the oil level in the middle of the red spot of the oil mirror

Fourth, the pump head will produce high temperature in the process of operation, do not touch



Packing List:

1 x Air compressor pump head
